1984 Audi 5000 Climate Control Troubleshooting and Repair Service Training Information. Original.

This troubleshooting booklet is divided into three sections:

Section 1 - Theory of operation with component and system descriptions, pages 2 through 13.
Section 2 - Symptom oriented diagnosis procedures, pages 14 through 57. This section begins with a 2 page diagnosis procedure to identify the symptom and check system performance. The individual symptoms with specific troubleshooting steps follow.
Section 3 - Repair procedures and specifications for the systems components along with wiring diagrams. This section begins on page 58.


Contents:

Climate control description
Components

Control head
Blower control unit
Blower thermo switch
Programmer
Temperature sensors

System Operation
Refrigeration System
Components

Expansion tube
Accumulator
Muffler
Thermostat
Ambient temp switch
Low pressure switch

Diagnosis and quality check procedure
Symptom diagnosis procedures
Repair information

Component description
Temperature sensors
Control head
Programmer
Blower control
Adjusting programmer
Vacuum servos for air distribution
Heat exchanger housing
Refrigerant system
Refrigerant system components
A/C compressor
Wiring diagrams
