1978 Ford Mercury Electrical & Vacuum Diagram LTD II Cougar XR7 T-Bird Ranchero

Price $32.78 $26.22 Details W: 17 x H: 11 x D: 0.25 Weight 0.94 lbs. Page Count 40 Condition Used Original - Good Item Type Factory Manual Inventory Number WD-9036 OEM Number 0338-506 In Stock
Flat US shipping rate: $8.95
Flat International shipping rate: $34.00

---

Description

Good original 1978 Ford/Mercury Dealer Electrical Wiring & Vacuum Diagram Service Manual. This manual was used by the Factory Dealership to diagnose and identify electrical and vacuum problems on the LTD II, Cougar XR7, T-Bird and Ranchero Models. It contains a wealth of information and will prove invaluable in service procedures on this model. 0338-506
